Lab Chemical Glove Box

Glove Box Chamber

• Glove Box : DECO-VGB-304-2

• Single Sided and Single Length (2 Ports)

• Case Material : Made of 6mm thickness 304 stainless steel sheet which provide heavy duty structure for vacuum

• Dimensions : 760mm(L) x 610mm(W) x 700mm(H)

• Full view front panels, 680mm(L) x 300mm(W) x 15mm(T)

• With 2 glove ports, Dia145mm

• Max. Positive Pressure : 0 MPa

• Max. Vacuum Level : -0.1 MPa

Antechamber

• Dimensions : 280mm(OD)x265mm(ID) x 300mm(L)

• 304 stainless steel, mounted on right end panel

• Manual antechamber ball valves for evacuation and refill

• Max. Vacuum Level : -0.1 MPa

Antechamber,   Mini

• Dimensions : 120mm(OD) x 200mm(L)

Glovebox Purge

• Manual 304 stainless steel ball valve. Standard feature.

LED Light

• 12V 28W 1800LM LED rigid bar, inner fixed over the window

Internal Power Extension

• One extension socket (Max power 6000W) is installed in the glove        box main chamber.

Gloves

• Size : 200mm(D) x 800mm(L) x 0.4mm(T)

• One pair of Black Butyl Gloves are included for immediate use

Vacuum   Pump

• Pumping rate : 2.1 CFM (3.6 m³/h)

• Rotary-vane Vacuum Pump

Application   Notes

• Always check the joints, gloves, sealing elements, and pipelines for air-tightness before and during the operation

• Corrosive gases are prohibited as they will damage the sensors

• The inlet and outlet of the Antechamber must not be opened at the same time to prevent contamination by the external gas
