Laboratory Jar Ball Mill
Laboratory Jar Ball Mill INTRODUCTION: When lab jar ball mill works, the grinding media and the materials in the jars raise to a certain height. Due to the gravity, they fall down from the tube wall. The materials are crushed under the impact action of the grinding media, also by the friction...
Description
Laboratory Jar Ball Mill
INTRODUCTION:
When lab jar ball mill works, the grinding media and the materials in the jars raise to a certain height. Due to the gravity, they fall down from the tube wall. The materials are crushed under the impact action of the grinding media, also by the friction and shearing action of the grinding media during rolling and sliding movement.
FEATURES:
1. Single or multi-tier design, one, two or four jars per tier
2. different size of jars can be used simultaneously
3. multiple samples can be ground simultaneously
4. adjustable rollers and brackets for different size of jars
SPECIFICATION:
Item NO.: | DECO-PM-1*5L | ||
Product name: | Laboratory jar ball mill | ||
Structure | Single Tier | ||
Grinding Tools | 1pcs Horizontal Grinding Jar | ||
Grinding Jar Volumes | 0.5L/1L/1.5L/2L/2.5L/3L/4L/5L | ||
Max Feed Size (depend on material) | < 10mm | ||
Final Fineness (depend on material) | Most materials 300~400mesh, minimum to 15μm | ||
Rotational Speed of Grinding Jar | 40~ 480rpm | ||
Electrical Details | 110VAC, 0.75KW, 60Hz | ||
Overall Dimension | W735*D425*H320mm |
APPLICATION:
Lab jar mill is extensively applied to in the fields of Geology, Mining, Metallurgy, Electronics, Construction Material, Ceramics, Chemical Engineering, Light Industry Medicine, Environmental Protection etc.
PACKING:
1 Standard exported package: Internal anticollision protection, external export wooden box packaging.
2 Shipping by express, by air, by sea according to customers' requirements to find the most suitable way.
3 Responsible for the damage during the shipping process, will change the damaged part for you for free.
